Tools for Saddles

  • Core Cutter L SDR11

    Core Cutter L SDR11

    for Saddles 110 mm (Available sizes: 2 Inch IT, 63, 90, 110, 125, 160 mm)

    ❯ The core cutters were developed for full-bore drilling of PLASSON saddles.
    ❯ Special design, adapted to drilling of saddles and pipes made of PE.

    Product details

  • Core Cutter L

    Core Cutter L

    for Saddles 4" IPS (Available sizes: 2"-4" IPS, 4 DIPS)

    ❯ The core cutters were developed for full-bore drilling of PLASSON saddles.
    ❯ Special design, adapted to drilling of saddles and pipes made of PE.

    Product details

  • Core Cutter XL SDR11

    Core Cutter XL SDR11

    for Saddles 250 mm (Available sizes: 180-250 mm)

    ❯ The core cutters were developed for full-bore drilling of PLASSON saddles.
    ❯ Special design, adapted to drilling of saddles and pipes made of PE.

    Product details

  • Core Cutter XXL SDR11

    Core Cutter XXL SDR11

    for Saddles 400 mm (Available XXL sizes: 280-400 mm)

    ❯ The core cutters were developed for full-bore drilling of PLASSON saddles.
    ❯ Special design, adapted to drilling of saddles and pipes made of PE.

    Product details

  • Saddle Clamp XL 225/250 mm

    Saddle Clamp XL 225/250 mm

    splitable, in suitcase, 225/250 mm (Available XL sizes: 180/200 mm, 225/250 mm)

    ❯ The saddle clamps were developed for use on PLASSON large-diameter branch saddles.
    ❯ In addition the clamping tool set 4_4701_009 is required. This includes the required tensioning material, strap ratchets and a torque wrench.

    Product details

  • Saddle Clamp XXL 355/400 mm

    Saddle Clamp XXL 355/400 mm

    splitable, in suitcase, 355/400 mm (Available XXL sizes: 280/315 mm, 355/400 mm)

    ❯ The saddle clamps were developed for use on PLASSON large-diameter branch saddles.
    ❯ In addition the clamping tool set 4_4701_009 is required. This includes the required tensioning material, strap ratchets and a torque wrench.

    Product details

  • Saddle clamp L 110 mm/3″ IPS

    Saddle clamp L 110 mm/3″ IPS

    splitable, in suitcase, (Available L sizes: 90-160 mm, 3-4 Inch IPS, 4 Inch DIPS)

    ❯ The saddle clamps were developed for use on PLASSON large-diameter branch saddles.

    Product details

  • Sensoradapter saddle clamping tool

    Sensoradapter saddle clamping tool

    The Clamping Toolkits for PLASSON Sensor Adapter Saddles are solely meant for the fixture and tensioning of PLASSON Sensor Adapter Saddles for PE pipes in the dimension range of 110-1200 mm as preparation for electrofusion (EF) Depending on the toolkit, it is either exclusively suitable for installation with the clamping screw, or for both the clamping screw and tension belt methods.

    Product details
